5454 aluminum sheet is a high-strength alloy known for its excellent corrosion resistance, particularly in marine environments and chemical applications. Widely used in the automotive, marine, and industrial sectors, 5454 aluminum sheet is the ideal material for projects requiring durability, formability, and resistance to harsh conditions. This alloy is particularly favored for its superior performance in saltwater and chemical environments, making it a top choice for demanding applications.

Product Characteristics

• Superior Corrosion Resistance: 5454 aluminum sheet offers outstanding resistance to atmospheric, marine, and chemical environments, making it ideal for outdoor and industrial applications.
• High Strength: This alloy provides a good balance of strength and weight, suitable for heavy-duty structural applications.
• Good Weldability: 5454 aluminum can be readily welded, ensuring strong joints and ease of fabrication.
• Excellent Formability: The alloy can be easily formed and shaped, allowing for a wide range of design possibilities.
• Good Machinability: 5454 aluminum can be easily machined, enabling precision fabrication of complex components.

Product Parameters

1. Thickness:

• Available in a range of thicknesses from 0.2 mm to 10 mm, catering to various application requirements.

2. Length:

• Standard lengths include 2000 mm, 3000 mm, 6000 mm, with custom lengths available upon request.

3. Width:

• Standard widths include 1000 mm, 1220 mm, 1500 mm, with custom widths available upon request.

4. Commonly Used States:

• H32, H34, H36, H38, and other tempers based on specific application needs.

5. 5454 Chemical Composition:

• Aluminum (Al): Balance
• Magnesium (Mg): 2.4-3.0%
• Manganese (Mn): 0.50-1.0%
• Iron (Fe): 0.4% max
• Silicon (Si): 0.25% max
• Copper (Cu): 0.1% max
• Chromium (Cr): 0.05-0.2%
• Zinc (Zn): 0.25% max
• Other Elements: 0.05% max (each), 0.15% max (total)

6. Mechanical Properties (Example for 5454-H34 Alloy):

• Tensile Strength: 38,000 psi (262 MPa)
• Yield Strength: 31,000 psi (214 MPa)
• Elongation: 12-16%
• Hardness (Brinell): 60 HB
• Density: 2.69 g/cm³

Applications

• Marine: Boat hulls, decks, and structural components.
• Automotive: Body panels, fuel tanks, and structural parts.
• Construction: Roofing, cladding, and structural supports.
• Industrial: Pressure vessels, pipelines, and storage tanks.
• Consumer Goods: Appliances, furniture, and outdoor equipment.

Conclusion

5454 aluminum sheet from AML aluminum company is engineered to meet the highest standards of quality and performance. Its exceptional corrosion resistance, strength, and formability make it the preferred choice for a wide range of applications. With customizable sizes and tempers, we ensure that you get the perfect material to meet your specific needs. Contact us today to learn more about our 5454 aluminum sheets and how they can enhance your projects.
