Overview

5056 aluminum wire is a high-strength, corrosion-resistant alloy widely used in marine, automotive, and industrial applications. Known for its excellent welding characteristics and resistance to saltwater corrosion, 5056 aluminum wire is the preferred material for projects requiring durability, lightweight properties, and reliable performance in harsh environments. Its superior formability and strength make it ideal for both structural and fabrication applications.

Product Characteristics

• Superior Corrosion Resistance: 5056 aluminum wire offers outstanding resistance to atmospheric and marine environments, making it ideal for coastal and offshore applications.
• High Strength: This alloy provides a strong balance of tensile and yield strength, suitable for demanding structural applications.
• Good Weldability: 5056 aluminum wire can be easily welded, ensuring strong joints and efficient fabrication processes.
• Excellent Formability: The alloy can be readily formed and shaped, allowing for versatile design options and complex geometries.
• Good Machinability: 5056 aluminum wire can be easily machined, enabling precise fabrication of detailed components.

Product Parameters

1. Thickness (Diameter):

• Available in a range of diameters from 0.5 mm to 10 mm, catering to various application requirements.

2. Length:

• Standard lengths include coils of 1000 m, 5000 m, and custom lengths available upon request.

3. Width:

• Not applicable for wire.

4. Commonly Used States:

• H32, H34, and other tempers based on specific application needs.

5. Chemical Composition:

• Aluminum (Al): Balance
• Magnesium (Mg): 4.5-5.6%
• Manganese (Mn): 0.05-0.2%
• Iron (Fe): 0.4% max
• Silicon (Si): 0.3% max
• Copper (Cu): 0.1% max
• Chromium (Cr): 0.05-0.2%
• Zinc (Zn):: 0.1% max
• Other Elements: 0.05% max (each), 0.15% max (total)

6. Mechanical Properties (Example for 5056-H32 Alloy):

• Tensile Strength: 45,000 psi (310 MPa)
• Yield Strength: 36,000 psi (250 MPa)
• Elongation: 12-18%
• Hardness (Brinell): 85 HB
• Density: 2.66 g/cm³

Applications

• Marine: Rigging, cables, and structural components.
• Automotive: Wiring harnesses, connectors, and structural parts.
• Construction: Structural supports, frameworks, and reinforcement.
• Industrial: Machinery parts, fasteners, and high-stress components.
• Consumer Goods: Appliances, hardware, and outdoor equipment.

Conclusion

5056 aluminum wire from kunxin aluminum company is engineered to meet the highest standards of quality and performance. Its exceptional corrosion resistance, strength, and formability make it the preferred choice for a wide range of applications. With customizable sizes and packaging options, we ensure that you get the perfect material to meet your specific needs. Contact us today to learn more about our 5056 aluminum wire and how it can enhance your projects.
