Overview

The 2017 aluminum plate is a high-strength, heat-treatable alloy known for its excellent mechanical properties and machinability. It is widely used in aerospace, automotive, and industrial applications that require superior strength, durability, and corrosion resistance. This alloy is particularly well-suited for structural components and heavy-duty applications due to its robustness and high performance under stress.

Product Characteristics

• High Strength: The 2017 aluminum plate offers exceptional tensile and yield strength, making it ideal for demanding structural applications.
• Excellent Machinability: This alloy is easy to machine, allowing for precise fabrication of complex components.
• Good Corrosion Resistance: 2017 aluminum provides good resistance to atmospheric corrosion, often enhanced through anodizing or coating for better protection in harsh environments.
• Heat Treatable: The alloy can be heat-treated to improve its mechanical properties and achieve desired strength levels.
• Fatigue Resistance: The 2017 aluminum plate exhibits excellent fatigue resistance, crucial for applications subjected to cyclic loads.

Product Parameters

1. Thickness:

• Available in a range of thicknesses from 1 mm to 150 mm, depending on specific requirements.

2. Length:

• Standard lengths include 2000 mm, 3000 mm, with custom lengths available upon request.

3. Width:

• Standard widths include 1000 mm, 1220 mm, 1500 mm, with custom widths available upon request.

4. Commonly Used States:

• T4, T451, T6, and other tempers based on application needs.

5. Chemical Composition:

• Aluminum (Al): Balance
• Copper (Cu): 3.5-4.5%
• Magnesium (Mg): 0.4-1.0%
• Manganese (Mn): 0.4-1.0%
• Iron (Fe): 0.7% max
• Silicon (Si): 0.2-0.8%
• Zinc (Zn): 0.25% max
• Chromium (Cr): 0.1% max
• Titanium (Ti): 0.15% max
• Other Elements: 0.05% max (each), 0.15% max (total)

6. Mechanical Properties (Example for 2017-T4 Alloy):

• Tensile Strength: 62,000 psi (427 MPa)
• Yield Strength: 40,000 psi (276 MPa)
• Elongation: 12-15%
• Hardness (Brinell): 120 HB
• Density: 2.80 g/cm³

Applications

• Aerospace: Structural components, aircraft fittings, and heavy-duty applications.
• Automotive: Engine components, high-performance parts, and suspension components.
• Industrial: Machinery parts, molds, and tooling.
• Construction: Structural supports, braces, and architectural elements.
• Marine: Boat frames, masts, and other critical components.

Conclusion

2017 aluminum plate from kunxin aluminum company is engineered to meet the highest standards of performance and reliability. Its exceptional strength, machinability, and corrosion resistance make it the preferred choice for a wide range of industrial applications. With customizable sizes and tempers, we ensure that you get the perfect material to meet your specific needs. Contact us today to learn more about our 2017 aluminum plates and how they can enhance your projects.
