Overview

1070 aluminum coil is a high-purity, corrosion-resistant material widely used in industrial, commercial, and consumer applications. Known for its excellent formability, high thermal and electrical conductivity, and superior performance, 1070 aluminum coil is the preferred choice for projects requiring reliable, lightweight, and durable material. Its versatility and ease of use make it ideal for a range of applications.

Product Characteristics

• High Purity: 1070 aluminum coil contains 99.7% aluminum, providing excellent ductility and corrosion resistance.
• Superior Corrosion Resistance: This alloy offers outstanding resistance to atmospheric and chemical environments, ensuring long-term durability.
• Excellent Formability: 1070 aluminum coil can be readily formed, allowing for versatile design options and complex geometries.
• High Thermal and Electrical Conductivity: The alloy is known for its excellent conductivity, making it suitable for electrical and thermal applications.
• Good Machinability: 1070 aluminum coil can be easily machined, enabling precise fabrication of detailed components.
• Lightweight: Despite its high purity, 1070 aluminum coil is lightweight, making it ideal for applications where weight reduction is crucial.

Product Parameters

1. Thickness:

• Available in a range of thicknesses from 0.2 mm to 6.0 mm, catering to various application requirements.

2. Length:

• Standard lengths include 2000 mm, 3000 mm, 6000 mm, with custom lengths available upon request.

3. Width:

• Standard widths include 1000 mm, 1220 mm, 1500 mm, with custom widths available upon request.

4. Commonly Used States:

• H14, H24, H18, and other tempers based on specific application needs.

5. Chemical Composition:

• Aluminum (Al): 99.7%
• Copper (Cu): 0.04% max
• Iron (Fe): 0.25% max
• Magnesium (Mg): 0.03% max
• Manganese (Mn): 0.03% max
• Silicon (Si): 0.20% max
• Titanium (Ti): 0.03% max
• Zinc (Zn): 0.04% max
• Other Elements: 0.03% max (each), 0.10% max (total)

6. Mechanical Properties (Example for 1070-H14 Alloy):

• Tensile Strength: 10,000-14,000 psi (70-95 MPa)
• Yield Strength: 4,000 psi (28 MPa)
• Elongation: 25-35%
• Hardness (Brinell): 25 HB
• Density: 2.71 g/cm³

Applications

• Industrial: Heat exchangers, chemical equipment, and insulation.
• Commercial: Signage, reflective surfaces, and decorative applications.
• Consumer Goods: Kitchenware, lighting, and packaging.
• Electrical: Conductors, bus bars, and heat sinks.
• Automotive: Body panels, heat shields, and trim.

Conclusion

1070 aluminum coil from kunxin aluminum company is engineered to meet the highest standards of quality and performance. Its exceptional purity, corrosion resistance, and formability make it the preferred choice for a wide range of applications. With customizable sizes and tempers, we ensure that you get the perfect material to meet your specific needs. Contact us today to learn more about our 1070 aluminum coils and how they can enhance your projects.
