Overview

7022 aluminum plate is a high-strength, corrosion-resistant alloy widely used in aerospace, industrial, and structural applications. Known for its excellent mechanical properties and superior performance, 7022 aluminum plate is the preferred material for projects requiring durability, lightweight properties, and reliable performance in demanding environments. Its exceptional formability and strength make it ideal for both structural and fabrication applications.

Product Characteristics

• Superior Corrosion Resistance: 7022 aluminum plate offers outstanding resistance to atmospheric and industrial environments, ensuring long-term durability.
• High Strength: This alloy provides a robust balance of tensile and yield strength, suitable for demanding structural applications.
• Excellent Weldability: 7022 aluminum can be easily welded, ensuring strong joints and efficient fabrication processes.
• Exceptional Formability: The alloy can be readily formed and shaped, allowing for versatile design options and complex geometries.
• Good Machinability: 7022 aluminum plate can be easily machined, enabling precise fabrication of detailed components.
• Lightweight: Despite its high strength, 7022 aluminum plate is lightweight, making it ideal for applications where weight reduction is crucial.

Product Parameters

1. Thickness:

• Available in a range of thicknesses from 1.0 mm to 100 mm, catering to various application requirements.

2. Length:

• Standard lengths include 2000 mm, 3000 mm, 6000 mm, with custom lengths available upon request.

3. Width:

• Standard widths include 1000 mm, 1220 mm, 1500 mm, with custom widths available upon request.

4. Commonly Used States:

• T6, T651, and other tempers based on specific application needs.

5. Chemical Composition:

• Aluminum (Al): Balance
• Magnesium (Mg): 1.0-1.5%
• Manganese (Mn): 0.10-0.35%
• Iron (Fe): 0.40% max
• Silicon (Si): 0.20% max
• Copper (Cu): 0.10% max
• Zinc (Zn): 5.0-6.0%
• Chromium (Cr): 0.10-0.25%
• Titanium (Ti): 0.10% max
• Other Elements: 0.05% max (each), 0.15% max (total)

6. Mechanical Properties (Example for 7022-T6 Alloy):

• Tensile Strength: 73,000 psi (500 MPa)
• Yield Strength: 64,000 psi (440 MPa)
• Elongation: 8-10%
• Hardness (Brinell): 130 HB
• Density: 2.80 g/cm³

Applications

• Aerospace: Structural components, fittings, and aircraft parts.
• Industrial: Machinery components, pressure vessels, and pipelines.
• Structural: Beams, columns, and framework components.
• Transportation: Automotive parts, railway components, and marine structures.
• Consumer Goods: Appliances, furniture, and outdoor equipment.

Conclusion

7022 aluminum plate from kunxin aluminum company is engineered to meet the highest standards of quality and performance. Its exceptional corrosion resistance, strength, and lightweight properties make it the preferred choice for a wide range of applications. With customizable sizes and tempers, we ensure that you get the perfect material to meet your specific needs. Contact us today to learn more about our 7022 aluminum plates and how they can enhance your projects.
