Overview

6005 aluminum extrusion is a high-strength, corrosion-resistant alloy widely used in structural, automotive, and industrial applications. Known for its excellent welding characteristics and superior performance, 6005 aluminum extrusion is the preferred material for projects requiring durability, lightweight properties, and reliable performance in demanding environments. Its exceptional formability and strength make it ideal for both structural and fabrication applications.

Product Characteristics

• Superior Corrosion Resistance: 6005 aluminum extrusion offers outstanding resistance to atmospheric and industrial environments, making it ideal for structural applications.
• High Strength: This alloy provides a strong balance of tensile and yield strength, suitable for demanding structural applications.
• Excellent Weldability: 6005 aluminum can be easily welded, ensuring strong joints and efficient fabrication processes.
• Exceptional Formability: The alloy can be readily formed and shaped, allowing for versatile design options and complex geometries.
• Good Machinability: 6005 aluminum extrusion can be easily machined, enabling precise fabrication of detailed components.

Product Parameters

1. Thickness:

• Available in a range of thicknesses from 1.0 mm to 10 mm, catering to various application requirements.

2. Length:

• Standard lengths include 2000 mm, 3000 mm, 6000 mm, with custom lengths available upon request.

3. Width:

• Standard widths vary based on specific extrusion profiles, with custom widths available upon request.

4. Commonly Used States:

• T5, T6, and other tempers based on specific application needs.

5. Chemical Composition:

• Aluminum (Al): Balance
• Magnesium (Mg): 0.40-0.70%
• Manganese (Mn): 0.10% max
• Iron (Fe): 0.35% max
• Silicon (Si): 0.60-0.90%
• Copper (Cu): 0.10% max
• Chromium (Cr): 0.10% max
• Zinc (Zn): 0.10% max
• Titanium (Ti): 0.10% max
• Other Elements: 0.05% max (each), 0.15% max (total)

6. Mechanical Properties (Example for 6005-T5 Alloy):

• Tensile Strength: 35,000 psi (240 MPa)
• Yield Strength: 28,000 psi (195 MPa)
• Elongation: 12%
• Hardness (Brinell): 75 HB
• Density: 2.70 g/cm³

Applications

• Structural: Beams, columns, and framework components.
• Automotive: Body panels, chassis parts, and structural supports.
• Construction: Roofing, cladding, and structural supports.
• Industrial: Machinery components, pressure vessels, and pipelines.
• Consumer Goods: Appliances, furniture, and outdoor equipment.

Conclusion

6005 aluminum extrusion from kunxin aluminum company is engineered to meet the highest standards of quality and performance. Its exceptional corrosion resistance, strength, and formability make it the preferred choice for a wide range of applications. With customizable sizes and tempers, we ensure that you get the perfect material to meet your specific needs. Contact us today to learn more about our 6005 aluminum extrusions and how they can enhance your projects.
