1100 Aluminum Sheet: Comprehensive Product Introduction

Overview

The 1100 aluminum sheet is a commercially pure aluminum grade known for its excellent corrosion resistance, high ductility, and excellent workability. This alloy is widely used in various industries, including chemical processing, food and beverage, and architectural applications. The 1100 aluminum sheet is ideal for projects that require a high degree of formability and resistance to corrosion but do not require high strength.

Product Characteristics

Excellent Corrosion Resistance

The 1100 aluminum sheet offers outstanding resistance to corrosion, making it suitable for use in environments exposed to moisture, chemicals, and other corrosive elements. This property makes it ideal for applications in the chemical and food processing industries.

High Ductility

One of the key characteristics of 1100 aluminum is its excellent ductility. This allows the material to be easily formed, bent, or shaped without cracking, making it perfect for applications that require complex shapes and fine details.

Superior Workability

The 1100 aluminum sheet is highly workable and can be easily machined, welded, or joined. Its soft and flexible nature makes it ideal for deep drawing, spinning, and other metalworking processes.

Reflective Finish

The material can be polished to a highly reflective finish, making it an attractive option for decorative applications as well as for use in lighting and reflective surfaces.

Lightweight

As with all aluminum alloys, the 1100 aluminum sheet is lightweight, offering significant advantages in transportation and handling, particularly in applications where weight reduction is crucial.

Product Parameters

Thickness

• Commonly available thicknesses: 0.2mm, 0.5mm, 1.0mm, 1.5mm, 2.0mm, 3.0mm
• Custom thicknesses available upon request

Length and Width

• Standard sizes: 4’x8′ (1220mm x 2440mm), 4’x10′ (1220mm x 3048mm)
• Custom dimensions can be provided to suit specific project needs

Commonly Used States (Temper)

• H14: Strain-hardened, partially annealed
• H18: Strain-hardened to a higher degree, providing more strength
• O: Annealed, for maximum ductility

Chemical Composition

• Aluminum (Al): 99.0% min
• Copper (Cu): 0.05-0.20%
• Silicon (Si): 0.05% max
• Iron (Fe): 0.4% max
• Zinc (Zn): 0.1% max
• Manganese (Mn): 0.05% max
• Other elements: 0.03% max each, 0.10% max total

Mechanical Properties (Example for 1100-H14)

• Tensile Strength: 110-145 MPa
• Yield Strength: 105 MPa
• Elongation: 12%
• Hardness: 35 Brinell

Applications

• Chemical Processing Equipment: Ideal for tanks, piping, and vessels due to its excellent corrosion resistance.
• Food and Beverage Industry: Used in containers, utensils, and packaging materials where purity and corrosion resistance are essential.
• Architectural Applications: Suitable for roofing, cladding, and decorative elements due to its reflective finish and workability.
• Reflective Surfaces: Commonly used in lighting fixtures, reflectors, and decorative applications where high reflectivity is desired.
• Heat Exchangers: Perfect for heat exchangers and heat sinks where thermal conductivity and corrosion resistance are important.

Conclusion

The 1100 aluminum sheet is an exceptional choice for a wide range of applications, offering excellent corrosion resistance, high ductility, and superior workability. Its lightweight nature and ability to be easily formed into complex shapes make it ideal for both industrial and decorative uses. With customizable options in thickness, size, and temper, the 1100 aluminum sheet can meet the specific needs of any project, ensuring both performance and visual appeal.
