1/8 Aluminum Plate: Product Overview

The 1/8 aluminum plate is a versatile and widely used material known for its excellent strength-to-weight ratio, corrosion resistance, and ease of fabrication. This aluminum plate is ideal for applications in industries such as construction, aerospace, automotive, and manufacturing, where durability and performance are crucial.

Product Characteristics

• High Strength: The 1/8 aluminum plate offers impressive strength while remaining lightweight, making it suitable for structural applications where both properties are essential.
• Corrosion Resistance: This aluminum plate is highly resistant to corrosion, making it ideal for use in environments exposed to moisture, chemicals, or harsh weather conditions.
• Lightweight: The 1/8 thickness provides a lightweight solution that is easy to handle and install, reducing overall project weight without compromising strength.
• Good Machinability: The plate is easy to cut, weld, and form, making it adaptable to various manufacturing processes and custom designs.
• Versatile Applications: Suitable for a wide range of uses, including marine parts, automotive panels, and industrial machinery components.

Product Parameters

• Thickness: The 1/8 aluminum plate has a standard thickness of 0.125 inches (approximately 3.175mm).
• Length: Available in standard lengths ranging from 1000mm to 6000mm, with custom lengths available upon request.
• Width: Common widths for the 1/8 aluminum plate range from 500mm to 2000mm, accommodating various application needs.
• Commonly Used States: The most commonly used temper states for this aluminum plate include H14, H24, and T6, offering different levels of hardness and flexibility depending on the application.

Chemical Composition

The chemical composition of the 1/8 aluminum plate typically includes:

• Aluminum (Al): 95.8% - 98.6%
• Magnesium (Mg): 0.8% - 1.2%
• Manganese (Mn): 0.4% - 1.0%
• Silicon (Si): 0.4% max
• Iron (Fe): 0.7% max
• Copper (Cu): 0.15% max
• Zinc (Zn): 0.25% max
• Chromium (Cr): 0.04% - 0.35%

Mechanical Properties

• Tensile Strength: 260 - 310 MPa, depending on the temper state
• Yield Strength: 240 - 280 MPa
• Elongation: 6% - 12%, varying by temper state and thickness
• Brinell Hardness: 95 - 105 HB, providing a good balance of hardness and workability

Conclusion

The 1/8 aluminum plate is a reliable and versatile material, offering a combination of strength, lightweight properties, and corrosion resistance. Its adaptability makes it a preferred choice for a wide range of applications across various industries. Whether you need a material for construction, automotive, or industrial projects, the 1/8 aluminum plate delivers performance and durability that meet your demands.
